 Organic fertilizer
 Chemical product: epoxy resin, caprolactame (C6H11NO), caustic soda(NaOH), oxalic acid
(COOH)2, phthalic anhydride (C8H4O3), ammonium chloride (NH4Cl), etc.
 Wooden pellet
 Industrial and alimentary salt

Auger Type Valve Bag Filler ( Screw Type Valve Bag Packing Machine)

The auger valve vag fillerin machine provides high speed delivery of product into bags, with
best weight control and easy operation. The auger is designed to provide minimum aeration of
product with consistent product flow and clean operation. Also included an agitator assists in
feeding of poor flowing products. This packer is ideal for low height area installations thanks
to its compact design. Its positive bag opening feature permits use of minimum bag size and
improves accuracy. The auger reverses at product filling cutoff to clear product from the
filling tube, thats prevents product dribbling when the filled bag is discharged.

Empty valve bag is simply placed on filling tube and the auto start signal is actuated. Filling,
weighing and cut-off at weight are fully automatic. TeknoConvey screw type valve bag filling
machines are fast, reliable and accurate!
Technical specifications of valve bag filler machines
 Heavy Duty Rugged Tubular Welded Frame.
 Best filling tube design for high weight accuracy.
 Designed to be used with the electronic weight controllers.
 Production rate up to 4 bag per minute
 Product applications: paint pigments, carbon black, chemicals, minerals, bakery mixes, etc.
 V hopper for free flowing products
 Sealed proximity switch for cut-off weight sensing
 Various auger rpm is available, including 900 and 1500 rpm
 Available stainless steel contact surfaces
 Bulk and dribble Filling
