              Cone shaped valve sealer on filling tube
              Hopper with ribbon agitator and rotary paddles
              Motors and electrical enclosures for ATEX or hazardous environments
              Inspection door with interlock switch
              Pneumatically actuated bag clamp
              Automatic start
              Powered bag discharge
               This  equipment  is  adapted  for;  Food,    flour,  spices,  feed,  feed  ingredients,  fish  feed,
               minerals,  coal,  talc, forestry,  wood flour, chemicals, extra fine chemicals, pigments, polymers
               resins and carbon black

               Ultrasonic Bag Sealer

               TeknoConvey Ultrasonic valve bag sealer effectively closes the bag’s valve before it is moved
               from  its original  filling  position.  This  bag  closer  ensures  a  highly  sanitary  operation  while
               handling dusty products. Innovative design utilizes an blowing filling tube collar, swirl air blast
               tube clean out, in addition to an ultrasonic sealer. A positive closure is obtained even through
               heavily contaminated valves. To fill  close bags cleanly, dust collection is active throughout the
               entire  cycle.    The  dust  puff  released  by  filled  bags  when  discharged  onto  the  conveyor  is
               completely eliminated by the sealed valve. Its simple design minimizes wearing parts.



















               Valve  bag  ultrasonic  sealer  converts  high  frequency  mechanical  sound  waves  on  a
               thermoplastic  material into frictional  heat creating a positive seal on applicable valve  bags.
               Ultrasonic  seal  has  been  specifically  designed  to  work  with  valve  bagging  equipment  and
               incorporates the latest ultrasonic sealing technology.
              Up to 3 bag per minute sealing rate depending on product
              Compatible with both plastic and paper valve sealable bags
              Seal prevents valve leakage or moisture intrusion
              Hermetic seals without excessive heat degradation to product
              Rigid mount sealer at fill spout decreases bag movement while maintaining bag shape



               Impeller Type Valve Bag Filling Machine

               Impeller valve bag filler  is rugged and cost effective equipment designed to handle powdered
               products  ranging  in  particle  size  from  under  microns  to  200  microns.    Fine  powders  are
               constantly and positively  impeller  fed which ensures smooth performance and tightly  filled
