contact part lifo tungsten carpite. Also we produce mixers all by stainless steel in order to meet
the high hygienic requirement.
Feeding & Discharging
A variety of feeding & discharging methods can be selected by the customers.
Continous operation
We can supply machines for continuous work when a large capacity per hour is needed for the
same material. Continuous ploughshare mixers differ from batch ploughshare mixers in that the
mass flow of the product is from the inlet of the container to the discharge at the opposite end.
Heating/Cooling jacket
Jacketed trough for heating/cooling operation
Extended height bases
Height of our Ribbon Mixer can be defined according to customer’s condition.
Vacuum drying and deaerating
The mixer can be designed for vacuum drying & deaerating for special applications.
Drive system
Drive system by geared motor, cycloidal reducer, worm reducer, belt or chain transmission, etc.
Spray nozzle
Liquid can be added into the powder by spray nozzles on the top.
Applications:
Paddle Mixer can be used wherever the Ploughshare Mixer is used, including but not limited to
compounding, fine mixing, dispersing, suspending, emulsifying, deaerating, tempering,
accelerating chemical or physical reactions, granulating, breaking down agglomerates, etc. It is
suited for such difficult processes as mixing trace elements in proportions of 1 in 100,000 to 1
in 1,000,000 parts.
Mixing Dryer And Reactor:
With some special modification, the TeknoMix Paddle Mixer can be used as a multi-stage
process vessel eliminating the need for additional specialist equipment. It can be used as a mixer
dryer, mixer-granulator, de-aerator, reactor and cooler.

Ribbon Mixer

Ribbon Mixers are versatile and efficient mixing and blending machines for mixing
of granules, dry powders, and viscous pastes homogeneously. They are able to give
perfect result for mixing due to the innovative design of spiral agitator inside of its
U shape chamber.
In a Ribbon Mixer, the powder or paste moves from center to the end of container
and also from end to the center. In such a three dimensional way, the total powder or
paste is mixed within the chamber. It asks for a short mixing time and relatively low
power consumption.
The unit consists of one electrical motor, one reduction gear, coupling, and shaft with
spiral agitator. The shaft is sealed with bush and gland housing at both ends.
Materials are loaded from top side, and the discharge is located at the bottom side in
the center. The discharge height can be adjusted as per requirement, so that material
gets discharged into the container below it without floating dust.
